Fiber-coupled light sources to provide highly efficient light coupling into a single optical fiber
The LEDs to run at high peak currents when in external trigger mode
A three-way switch to move the light source between continuous, off and trigger modes

Part #	Wavelength	FWHM	Min Power coupled into a 600 um .22NA fiber	Maximum Drive Current CW	Maximum Drive Current Pulsed	Maximum duty Cycle in pulsed mode
LLS-240	240 nm	11 nm	2 μW	30 mA	200 mA	1%*
LLS-250	250 nm	12 nm	5 μW	30 mA	200 mA	1%*
LLS-270	270 nm	12 nm	15 μW	30 mA	200 mA	1%*
LLS-290	290 nm	12 nm	15 μW	30 mA	200 mA	1%*
LLS-310	310 nm	12 nm	15 μW	30 mA	200 mA	1%*
LLS-325	325 nm	12 nm	15 μW	30 mA	200 mA	1%*
LLS-345	345 nm	12 nm	20 μW	30 mA	200 mA	1%*
LLS-365	365 nm	9 nm	1 mW	500 mA	1000 mA	50%
LLS-385	385 nm	10 nm	1 mW	500 mA	1000 mA	50%
LLS-405	405 nm	14 nm	750 μW	500 mA	1000 mA	50%
LLS-455	455 nm	20 nm	1 mW	1500 mA	3000 mA	50%
LLS-470	470 nm	25 nm	1 mW	1500 mA	3000 mA	50%
LLS-505	505 nm	30 nm	1 mW	1500 mA	3000 mA	50%
LLS-530	530 nm	35 nm	750 μW	1500 mA	3000 mA	50%
LLS-590	590 nm	14 nm	750 μW	700 mA	1400 mA	50%
LLS-617	617 nm	20 nm	750 μW	700 mA	1400 mA	50%
LLS-627	627 nm	20 nm	750 μW	700 mA	1400 mA	50%
LLS-Warm White	VIS 3000K CCT	N/A	1 mW	1500 mA	3000 mA	50%
LLS-Neutral White	VIS 4100K CCT	N/A	1 mW	1500 mA	3000 mA	50%
LLS-Cool White	VIS 6500K CCT	N/A	1 mW	1500 mA	3000 mA	50%
